Zurn ZANB1461-12 12″ x 12″ Nickel Bronze Hinged Floor Access Panel
Product Overview
The Zurn ZANB1461-12 Floor Access Panel is a durable, hinged access solution designed for commercial plumbing, mechanical, and utility applications. Built from nickel bronze with a polished scoriated cover, this access panel combines strength with a clean, professional appearance.
Set flush with finished floors or walls, the ZANB1461-12 provides reliable access to concealed valves, pipes, and equipment while maintaining a low-profile design. Its hinged construction allows easy opening and secure closure, making it ideal for light-duty use in commercial, institutional, and multi-unit facilities.
Features & Benefits
-
Flush installation – sits level with finished floor or wall for a clean look
-
Nickel bronze polished cover – corrosion resistant and visually appealing
-
Hinged design – allows quick, repeated access to concealed equipment
-
Anchor lugs included – ensures secure installation in concrete or masonry
-
Scoriated surface – improves traction for safer foot traffic when floor mounted
-
Low-profile design – suitable for commercial and institutional light-duty applications
Specifications
-
Model Number: ZANB1461-12
-
Size: 12″ × 12″ (305 mm × 305 mm)
-
Material: Nickel bronze with polished scoriated cover
-
Frame: Secured frame with anchor lugs
-
Installation: Flush mount for floor or wall access
-
Weight: Approx. 11 lb (5 kg)
-
Options Available:
-
Z1461 (Cast Iron, Dura-Coated)
-
ZAB1461 (Polished Bronze)
-
ZANB1461 (Polished Nickel Bronze)
-
-VP suffix (Vandal-proof screws)
-
Installation Tips
-
Ensure opening dimensions match the 12″ × 12″ frame size before installation.
-
Use anchor lugs for secure placement in concrete or masonry floors/walls.
-
Install flush with finished surface for both safety and aesthetics.
-
Select vandal-proof screws if tamper resistance is required.
-
Follow local building codes and ADA requirements when installing in occupied spaces.
FAQs
Q: What is this panel used for?
It provides access to concealed valves, pipes, or mechanical equipment in commercial buildings.
Q: Can this be used in both floors and walls?
Yes, it is designed for flush installation in either location for light-duty applications.
Q: Is the surface slip-resistant?
Yes, the scoriated (textured) surface improves traction when floor mounted.
Q: What finish is included on the ZANB1461-12?
It features a nickel bronze polished cover, resistant to corrosion and wear.
Q: Does it come in other materials?
Yes, the Z1461 series is available in cast iron, bronze, or nickel bronze, depending on your project needs.
