Zurn Z160 Cast Iron Scupper Drain with 135° Angled Bronze Grate
Product Overview
The Zurn Z160 Series Scupper Drain is designed for secondary drainage on pitched roof systems, providing controlled overflow protection during heavy rain events. Featuring a 135-degree angled outlet and a Dura-Coated cast iron body, the Z160 delivers durable performance and efficient water discharge through parapet walls. An integral membrane clamp ensures a secure, watertight installation, while optional bronze or nickel bronze grates provide a clean, architectural finish.
Features & Benefits
- 135-degree angled scupper drain for efficient roof overflow drainage
- Dura-Coated cast iron body for long-term durability
- Integral membrane clamp for watertight roof integration
- Available with bronze or nickel bronze grate options
- Supports 4″ and 6″ threaded outlet connections
Specifications
- Series: Zurn Z160
- Drain Type: Scupper drain
- Angle: 135-degree outlet
- Body Material: Dura-Coated Cast Iron
- Grate Options: Plain Bronze (ZRB-160), Polished Bronze (ZB-160), Nickel Bronze (ZN-160)
- Connection Sizes: 4″, 6″
- Connection Type: Threaded
Installation Tips
- Install as a secondary roof drain per applicable building codes.
- Tighten membrane clamp evenly for a watertight seal.
- Align the 135-degree outlet through the parapet wall opening.
- Select grate finish based on exposure and appearance requirements.
FAQs
Q1: What is this drain used for?
Secondary drainage on pitched roof systems.
Q2: Why does it use a 135-degree angle?
To efficiently direct water through parapet walls.
Q3: What grate finishes are available?
Plain bronze, polished bronze, and nickel bronze.
Q4: What connection sizes are supported?
4″ and 6″ threaded connections.
Q5: Is this suitable for commercial roofs?
Yes, it is widely used in commercial roofing systems.
