Zurn Z1022-XL-DU3-LT Sani-Gard Automatic Trap Primer 3-Outlet Distribution Unit

Description

ZURN Z-1022-XL-DU3-LT Sani-Gard Automatic Trap Primer 3-Outlet Distribution Unit.

Engineering Specification:

ZURN Z1022-XL-DU3 Low-Lead Sani-Gard Automatic Trap Primer, all bronze body with integral vacuum breaker, non-liming internal operating piston, stainless steel spring, removable bronze seat with metering orifice, and sealed bronze cover. Distribution Unit furnished with all brass body, inlet adapter, internal slotted water metering tubes, overflow ports, removable, gasketed transparent cover, complete with (3) 3/8″ [10mm] NPT outlet connections.

NOTES:

• Z-1022-XL TRAP PRIMER SOLD SEPARATE.
• This product complies with the lead content requirements as outlined in the Federal Reduction of Lead In Drinking Water Act.
