Tekmar 003 Relay 24V

Features:

• Double Pole Double Throw relay (DPDT) to isolate electrical loads

• Easy to replace (“ice cube” style – no need to remove wiring)

• LED to indicate when energized

• Test button for easy test and manual override

Specifications:

• Packaged Weight – 0.4lb
• Dimensions – 3″ H x 1-9/16″ W x 2-3/8″ D
• Approvals – CSA C US
• Power Supply (Coil) – 24V (ac) +10%, -20%, 50Hz 2.7VA, 60Hz 2.3VA
• Relay Contacts (Max) – 10 A Resistive at 250V (ac) N.O. ,N.C. – 10 A Resistive at 30V (dc) N.O., N.C. – 7 A Inductive at 250V (ac)
• Relay Contacts (Min) – 10mA 1V (dc)
• Warranty – Limited 3 Year Warranty
