Description
24W Dual Head Recessed Downlight 38°
The Rayhil Sonic Multiple Series cultivates a fresh unique look that defines any commercial or residential space. The flawless engineering of the extruded aluminum heat sink ensures optimal heat dissipation and LED life. The Multiple Head Downlights are Type IC rated – approved for direct contact with insulation and have an isolated driver inside a junction box.
Additionally, they are air-tight and wet location approved. The gimbal can rotate 360 degrees horizontally and tilt 30 degrees. Available in both 2-Head and 3-Head as well as multiple color temperature and trim options.
- Air-tight and damp location approved Type IC rated
- Approved for direct contact with insulation Isolated driver inside junction box
- New Construction plate available (NCH2H)
- Extruded aluminum heat sink ensures optimal heat dissipation and LED life
- 360° rotatable Gimbal with 30° horizontal tilt
- Selectable CCT (30K/35K/40K)
Click Here for New Construction Plate
Dimensions
Cutout
|
Spec Sheet
Spec Sheet
Installation Instructions
Info
| Wattage | 24W (2-12W Luminaires) |
| Lumen | 1750lm |
| Efficacy(LPW) | >75 lm/W |
| Color Temp | 30K/35K/40K |
| CRI | >90 |
| Beam Angle | 38° |
| Dimming | Triac/ 0-10V |
| Lamp Life | 50,000hr |
| Environment | Damp Location |
