006 Stainless Steel Circulator Pump, 3/4″ NPT, 1/40 HP, 115V

Description

Taco 006-ST4 Stainless Steel Circulator Pump is designed for circulating hot or chilled fresh water in open or closed loop applications. Common uses include hydronic heating, chilled water cooling, and domestic hot water systems, hydro-air heating/cooling, heat recovery units, water source heat pumps, drain down open loop solar systems and potable water applications.
Stainless Steel Taco 006-ST4 Circulator Pump features a unique replaceable cartridge which allows for easy service, instead of replacing the entire circulator. Taco 006-ST4 Circulator pump is compact, direct-drive, features low power consumption and is ideal for high-efficiency jobs.

Applications:

• Domestic Hot Water Recirculation;
• Hydronic Heating / Cooling;
• Radiant Heating;
• Heat Recovery Units;
• Solar;
• And many others;

Cross-References:

• Taco 006-BT4

Technical Specifications:

• Flow Range: 0 – 10 GPM;
• Head Range: 0 – 9 Feet;
• Minimum Fluid Temperature: 40˚F (4˚C);
• Maximum Fluid Temperature: 220°F (104˚C);
• Maximum Working Pressure: 125 psi;
• Connection Sizes: 3/4 NPT threaded;
• Voltage: 115V;
• Hertz: 60Hz;
• Phase: 1;
• Amps: 0.52 Amps;
• HP: 1/40HP;
